CMP Products – PATRIOT Series Cable Cleats

Technicial Specifications:

• Certificate obtained from an independent organization in accordance with IEC 61914 Standard
• 135kA short circuit resistance
• 316L Stainless Steel Body
• Structure resistant to weather conditions and sunlight (UV)
• -50°C …+60°C standard operating temperature
• Fixing capacity in the cable outer diameter range of 17 mm – 128 mm
• 24 different Trefoil Structure size options
• Single bolt (M10) and two bolt (M10) fixing options
