‹ › SCHUCH - ExSPECT e9310 LED Ex-proof Hand Lamp

Click to enlarge

SCHUCH - ExSPECT e9310 LED Ex-proof Hand Lamp

SCHUCH

The SCHUCH ExSPECT e9310 is a portable LED hand lamp certified for Zone 1, 21 and Zone 2, 22. Its gas marking is II 2G Ex eb mb op is IIC T4 Gb and its dust marking II 2D Ex op is tb IIIC T80°C Db, with an IP66 housing. Supply is 220–240V AC/DC and the ambient range is -25°C to +40°C.

Get a Quote
Zone 1 / 2 / 21 / 22 Protection IP66 Temperature -25°C … 40°C Certification ATEX · IECEx

Categories: Ex-proof Products, Ex-proof Lighting Fixtures

Share:

Technical specifications

  • Ex-proof zone classification: Zone 1, 21 / Zone 2, 22
  • Explosion protection (gas): II 2G Ex eb mb op is IIC T4 Gb
  • Explosion protection (dust): II 2D Ex op is tb IIIC T80°C Db
  • Ingress protection: IP66
  • Operating voltage: 220–240V AC/DC, 0 or 50/60Hz
  • Ambient operating temperature: -25°C to +40°C
  • ATEX certificate: IBExU 19 ATEX 1134
  • Other certifications: IECEx IBE 19.0028
Need this product for your project? Our engineers help you choose the right model and prepare a quotation.
Get a Quote Documents
